RALLY BAR + TAPCAT5E + MIC PODS – TAA COMPLIANT

The Logitech Rally Bar Room Kit is designed to transform any meeting space into a modern conference room. Offering excellent audio and video quality, this kit features a 6-microphone array with beamforming technology and a high-definition video camera capable of up to 4K resolution. Users will enjoy seamless interaction through a 10.1-inch touchscreen with an anti-fingerprint coating, ensuring clear visibility and easy operation. With comprehensive connectivity options, including Bluetooth, Ethernet, and Wi-Fi, setting up and starting meetings is hassle-free. Certified for Microsoft Teams Rooms, Google Meet, and Zoom, it’s the ideal solution for any organization looking to enhance their conferencing capabilities. Additionally, the Logitech Rally Bar Room Kit prioritizes security with features like AES-128 encryption and API inspection, ensuring that your communications remain private and secure.

• Primary Information

  Product Description:	Logitech Rally Bar Room Kit – video conferencing kit – TAA Compliant
  Device Type:	Video conferencing kit
  Kit Content:	Logitech Rally Bar, Logitech Tap with Cat5e Kit, 2 mic pods
  Display:	10.1″ 1280 x 800
  Video Input:	Digital video camera – SuperSpeed USB 3.0
  Audio Input:	6-microphone array – omni-directional, beamforming
  Audio Output:	Speaker(s)
  Input Device:	10.1″ touchscreen, remote control, two microphones (wireless, wired)
  Networking:	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth LE
  Power:	AC 100-240 V
  TAA Compliant:	Yes
  Software Certification:	Certified for Microsoft Teams Rooms, Zoom Certified, Google Meet Certified
  Manufacturer Warranty:	2-year warranty

• General

  Device Type:	Video conferencing kit
  Kit Content:	Logitech Rally Bar, Logitech Tap with Cat5e Kit, 2 mic pods
  Dimensions & Weight Details:	Video bar – Width 35.8 in Depth 5.1 in Height 6.5 in Weight 15.6 lbs ¦ Power adapter (video bar) – Width 5 in Depth 2 in Height 1.2 in ¦ Touch screen – Width 9.6 in Depth 7 in Height 2.3 in Weight 2.8 lbs ¦ Microphone – Width 4 in Depth 4 in Height 0.8 in

• Display

  Diagonal Size:	10.1″
  Native Resolution:	1280 x 800
  Monitor Features:	Kensington Security Slot, touch screen, 100 x 100 VESA mounting, fingerprint-resistant oleophobic coating, anti-fingerprint, integrated PIR motion sensor

• Video Input

  Type:	Digital video camera (color) – desktop / wall mountable
  Interface Type:	SuperSpeed USB 3.0
  Video Modes:	480p, 720p, 1080p, 4K, 1440p, 900p
  Optical Zoom:	5
  Digital Zoom:	3
  Camera Mechanical Design:	Pan / tilt / zoom
  Features:	RightSense technology, RightSight technology, RightLight technology, RightSound technology, AI Viewfinder technology, Wide Dynamic Range (WDR), Acoustic Echo Cancellation (AEC), Voice Activity Detector (VAD), 30 fps, -25° / +25° pan, -15° / +15° tilt, 52.2° field of view (vertical), 82.1° field of view (horizontal), 90° diagonal field of view, AI-powered, microphone noise suppression technology

• Audio Input

  Type:	6-microphone array – integrated
  Microphone Operation Mode:	Omni-directional, beamforming
  Frequency Response:	90 – 16000 Hz

• Audio Output

  Type:	Speaker(s)
  Total Harmonic Distortion (THD):	<2%

• Input Device

  Type:	10.1″ touchscreen, remote control, two microphones
  Connectivity Technology:	Wireless, wired

• Networking

  Connectivity Technology:	Wireless, wired
  Data Link Protocol:	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth LE
  Features:	Cable management, AES encryption, MIMO technology, Public Key Infrastructure (PKI), symmetric key encryption, API inspection, ARM TrustZone
  Compliant Standards:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac

• Expansion / Connectivity

  Interfaces:

  2 x display / video – HDMI output ¦ 2 x display / video – HDMI input ¦ 3 x SuperSpeed USB 3.0 – 9 pin USB Type A ¦ 1 x USB-C 3.0 – 24 pin USB-C ¦ 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ 1 x USB-C 3.1 – 24 pin USB-C ¦ 1 x microphone – input – mini-phone 3.5 mm 4-pole ¦ 1 x USB 2.0 – 4 pin USB Type A

• Miscellaneous

  Cables Included:	1 x AC power cable – 3.3 ft ¦ 1 x DC power cable – 5 ft ¦ 1 x HDMI cable – 6.6 ft ¦ 1 x USB 3.0 Type C to Type A cable – 7 ft ¦ 1 x CAT5E network cable – 9.7 ft ¦ 1 x CAT5E network cable – 23 ft
  Included Accessories:	Remote control, Logitech tap receiver, microfiber cloth, dongle transceiver, lens cap
  Software Certification:	Certified for Microsoft Teams Rooms, Zoom Certified, Google Meet Certified
  Compliant Standards:	Plug and Play, NDAA, AES-128
  TAA Compliant:	Yes

• Power

  Power Device:	Power adapter – external
  Voltage Required:	AC 100-240 V

• Manufacturer Warranty

  Service & Support:

  Limited warranty – 2 years

• Environmental Parameters

  Min Operating Temperature:	32 °F
  Max Operating Temperature:	104 °F
  Humidity Range Operating:	10 – 95%

• Special Feature

  COO:	UNITED STATES

• UNSPSC Code

  UNSPSC Code:

  45111902
