Tripp Lite 5/5.8kW Single-Phase Switched PDU with LX Platform Interface, 208/240V Outlets (20 C13 & 4 C19), L6-30P, 0U, TAA – power distribution unit
$891.99
Eaton 5.5kW Single-Phase Switched PDU – LX Interface, 208/230V Outlets (20 C13 & 4 C19), L6-30P, 0U, TAA
Description
The PDUMV30HVNETLX 5/5.8kW Single-Phase Switched PDU provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. Recommended for any IT or industrial application, it features 24 switched outlets (20 C13 and 4 C19). LEDs indicate each outlet’s on/off power status. A 10-foot cord with NEMA L6-30P plug connects the PDU to a compatible AC power source, generator or protected UPS.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.
A digital ammeter allows you to monitor each bank’s load in real time to ensure it remains well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
- NEMA L6-30P input with 10 ft. AC power cord
- Digital ammeter for on-site load monitoring in real time
- Built-in LX Platform interface for remote access
- 5/5.8kW 208/240V 30A switched PDU
- 24 individually controllable outlets-20 C13, 4 C19
Specification
Additional information
| Weight | 11.5 kg |
|---|---|
| Dimensions | 2.7 × 2.2 × 70 cm |
| product type | PDU |
| environmentally friendly | Yes |
| taa compliant | Yes |
| mounting orientation | Vertical |
| environmental compliance | Restriction of Hazardous Substances (RoHS) |
| country of origin | Taiwan |
| rack height | 0U |
| brand name | Tripp Lite by Eaton |
| manufacturer | Tripp Lite by Eaton |
| product model | PDUMV30HVNETLX |
| product name | PDUMV30HVNETLX 24-Outlet PDU |
| mount type | Rack-mountable |
| manufacturer part number | PDUMV30HVNETLX |
| manufacturer website address | https://tripplite.eaton.com/ |
| package contents | <ul> <li>PDUMV30HVNETLX 24-Outlet PDU</li> <li>Configuration Cable</li> <li>24 x Cable Ties</li> <li>2 x Cord Retention Brackets</li> <li>Rack-mounting Hardware</li> <li>Mounting Bracket Accessory</li> <li>Owner's Manual</li> </ul> |
| limited warranty | 2 Year |
| weight (approximate) | 11.50 lb |
| upc | 818216955317 |
| brand | Tripp Lite by Eaton |
| part_number | PDUMV30HVNETLX |
