- Intel Core i5-1335U, 10C (2P + 8E)/12T, P-core 1.3/4.6GHz, E-core 0.9/3.4GHz, 12MB
- 16" WUXGA (1920x1200) IPS 300nits 45% NTSC
- 8GB DDR4-3200 + 8GB SO-DIMM DDR4-3200
- 256GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0
- Intel Iris Xe Graphics
- Windows 11 Pro
Intel Core i5-1335U, 10C (2P + 8E)/12T, P-core 1.3/4.6GHz, E-core 0.9/3.4GHz, 12MB, 8GB DDR4-3200 + 8GB SO-DIMM DDR4-3200, 256GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0, 16" WUXGA (1920x1200) IPS 300nits 45% NTSC, Intel Iris Xe Graphics, Intel Wi-Fi 6 AX201 802.11ax 2x2 + BT5.1, Windows 11 Pro
Get more work done, anywhere
You can configure the ThinkPad T16 to meet your needs on the go, and then some. Choose from up to Intel vPro® with 12th Gen Intel® Core™ i7 vPro® processing, up to 2TB Gen 4 performance of PCIe storage, and up to a massive 48GB of DDR4 memory. You can also opt for Intel® Iris® Xe or NVIDIA® GeForce® discrete graphics. Now, you can work all day, and game or binge-watch all night.
Being productive just got more fun
On audio and visuals, the ThinkPad T16 simply excels. It has various 16" display options, including a WQXGA screen with Dolby Vision™ and certified Eyesafe® low blue-light technology. Each display has as an expansive 16:10 aspect ratio with expanded vertical screen real estate, improving productivity and downtime. It also comes with Dolby Audio™ and Dolby Voice® AI noise-suppressing technology as standard.
Be in the loop, wherever life takes you
Perfect for the modern professional, the ThinkPad T16 has a choice of large-capacity batteries, each able to run all-day on a single charge. There is an array of ports, including Intel® Thunderbolt™ 4 and HDMI, plus blazing-fast connectivity options, including Intel® WiFi 6E. It also has a full-sized keyboard with a number pad, ideal for number-crunching on the go.
Smarter security, from the inside out
To help protect your data and your business from growing cyber threats, ThinkPad T16 has a number of robust ThinkPad and ThinkShield security features. This includes a PrivacyGuard display and a biometric Power-On touch fingerprint reader, plus Intel vPro® hardware-based security. In addition, the optional FHD + IR camera will detect if someone is viewing your screen over your shoulder.
Powerful yet sustainable
Even with all its productivity- and creativity-enhancing features, this ThinkPad was designed with the planet in mind. We used recycled post-consumer content (PCC), such as plastic and natural materials, in various components, including the speaker enclosure, battery compartment, and adapter. It also comes with recycled and/or sustainably forested packaging and recycled PCC cardboard cushioning.
Reliability & durability you can trust
We use the US Department of Defense's MIL-STD 810H standards to create a balance of reliability and durability for our ThinkPad laptops. Measured against 12 stringent standards and more than 200 quality checks, they’re able to run in the harshest of conditions, from the Arctic wilderness to desert dust storms. Our tests also include temperature, pressure, humidity, vibration, and more.
| Design |
|---|
| Product type |
Laptop |
| Product colour |
Black |
| Colour name |
Graphite black |
| Form factor |
Clamshell |
| Display back cover material |
Aluminium |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC) |
| Display |
|---|
| Display diagonal |
40.6 cm (16") |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| HD type |
WUXGA |
| Panel type |
IPS |
| Native aspect ratio |
16:10 |
| LED backlight |
Yes |
| Anti-glare screen |
Yes |
| Display brightness |
300 cd/m² |
| Colour gamut |
45% |
| RGB colour space |
NTSC |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (typical) |
800:1 |
| Processor |
|---|
| Processor manufacturer |
Intel |
| Processor family |
Intel® Core™ i5 |
| Processor generation |
13th gen Intel® Core™ i5 |
| Processor model |
i5-1335U |
| Processor cores |
10 |
| Processor threads |
12 |
| Processor boost frequency |
4.6 GHz |
| Performance cores |
2 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
4.6 GHz |
| Efficient-core Max Turbo Frequency |
3.4 GHz |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
| Maximum turbo power |
55 W |
| Processor base power |
15 W |
| Memory |
|---|
| Internal memory |
16 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory clock speed |
3200 MHz |
| Memory form factor |
On-board + SO-DIMM |
| Memory layout (slots x size) |
1 x 8 GB |
| Memory slots |
1x SO-DIMM |
| Maximum internal memory |
40 GB |
| Memory channels |
Dual-channel |
| Storage |
|---|
| Total storage capacity |
256 GB |
| Storage media |
SSD |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| NVMe |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD form factor |
M.2 |
| Optical drive type |
No |
| Card reader integrated |
No |
| Graphics |
|---|
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Iris Xe Graphics |
| On-board graphics card model |
Intel Iris Xe Graphics |
| Audio |
|---|
| Audio chip |
Synaptic CX11880 |
| Audio system |
Dolby Atmos |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Number of microphones |
2 |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera HD type |
Full HD |
| Front camera resolution |
1920 x 1080 pixels |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6 AX201 |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.1 |
| Near Field Communication (NFC) |
No |
| WWAN |
Not installed |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Thunderbolt 4 ports quantity |
1 |
| Intel® Thunderbolt 4 |
Yes |
| Combo headphone/mic port |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Sleep-and-Charge |
Yes |
| USB Sleep-and-Charge ports |
1 |
| Performance |
|---|
| Motherboard chipset |
Intel SoC |
| Keyboard |
|---|
| Pointing device |
ThinkPad UltraNav |
| Keyboard backlit |
Yes |
| Numeric keypad |
Yes |
| Spill-resistant keyboard |
Yes |
| Keyboard language |
US English |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system language |
English |
| Battery |
|---|
| Battery technology |
Lithium Polymer (LiPo) |
| Battery capacity |
47 Wh |
| Fast charging |
Yes |
| Power |
|---|
| AC adapter power |
65 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Type-C charging port |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| Security |
|---|
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Smart card reader |
No |
| Fingerprint reader |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Password protection |
Yes |
| Password protection type |
HDD, Power on, Supervisor |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Maximum shipping altitude |
3048 m |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Certification |
FSC certified packageErP Lot 6ErP Lot 26MIL-STD-810H |
| Sustainability |
|---|
| Sustainability certificates |
TCO, ENERGY STAR, EPEAT Gold |
| Weight & dimensions |
|---|
| Weight |
1.77 kg |
| Width |
356.1 mm |
| Depth |
247.7 mm |
| Height |
19.9 mm |
| General |
|---|
| Product series |
E |
| Product family |
ThinkPad |
| Packaging content |
|---|
| AC adapter included |
Yes |
