Power-saving outlets
- Automatically cuts power to idle equipment to conserve electricity.
Disconnected battery notification
- Warns when a battery is not available to provide backup power.
Boost and Trim Automatic Voltage Regulation (AVR)
- Gives higher application availability by correcting low and high voltage conditions without using the battery.
LCD graphics display
- Text and mimic diagrams that display modes of operation, system parameters and alarms.
| Features | |
|---|---|
| Audible alarm(s) | Yes |
| Noise level | 40 dB |
| Surge energy rating | 355 J |
| Output power | 420 W |
| Output power capacity | 0.7 kVA |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| AC outlet types | NEMA 5-15R |
| Battery | |
|---|---|
| Battery recharge time | 12 h |
| Battery technology | Sealed Lead Acid (VRLA) |
| Design | |
|---|---|
| LED indicators | Yes |
| Cable length | 1.83 m |
| Product colour | Black |
| Operational conditions | |
|---|---|
| Non-operating altitude | 0 - 3000 m |
| Operating altitude | 0 - 3000 m |
| Storage relative humidity (H-H) | 0 - 40% |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -14 - 40 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Certificates | |
|---|---|
| Certification | FCC Part 15 Class B, FCC Part 68, NOM, UL 1778 |
| Weight & dimensions | |
|---|---|
| Weight | 7.15 kg |
| Packaging data | |
|---|---|
| Package weight | 7.95 kg |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85078000 |
| Other features | |
|---|---|
| Package dimensions (WxDxH) | 138 x 442 x 252 mm |
| Nominal output voltage | 120 V |
| Nominal input voltage | 120 V |
| Filtering | Yes |
| Dimensions (WxDxH) | 91 x 310 x 190 mm |
| Output connections | 3 x NEMA 5-15R3 x NEMA 5-15R |
| size |
700VA |
|---|
